Dell PowerConnect 5424 Command Line Interface Guide

Configuration and Image 145
Use the copy source-url running-config command to load a "configuration file" from a network server
to the device "running configuration". The configuration is added to the "running configuration" as if
the commands were typed in the command-line interface (CLI). The resulting configuration file is a
combination of the previous "running configuration" and the loaded "configuration file", with the
loaded "configuration file" having precedence.
Copying a Configuration File from a Server to the Startup Configuration
Use the copy source-url startup-config command to copy a "configuration file" from a network server
to the device "startup configuration". These commands replace the startup configuration file with the
copied configuration file.
Storing the Running or Startup Configuration on a Server
Use the copy running-config destination-url command to copy the current configuration file to a
network server using TFTP. Use the copy
startup-config destination-url command to copy the "startup
configuration" file to a network server.
The configuration file copy can serve as a backup copy.
Saving the Running Configuration to the Startup Configuration
Use the copy running-config startup-config command to copy the "running configuration" to the
"startup configuration".
Backup the Running Configuration or Startup Configuration to a Backup Configuration file
Use the copy running-config flash: //FILE_NAME to backup the running configuration to the backup
configuration file. Use the
copy startup-config flash: //FILE_NAME command to backup the startup
configuration to the backup configuration file.
Examples
The following example copies a system image named file1 from the TFTP server with an IP address of
172.16.101.101 to non active image file.
Console# copy tftp://172.16.101.101/file1 image
Accessing file 'file1' on 172.16.101.101...
Loading file1 from 172.16.101.101:
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!! [OK]
Copy took 0:01:11 [hh:mm:ss]
5400_CLI.book Page 145 Wednesday, December 17, 2008 4:33 PM

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
