Verifying One Floor Run Operation
4-3
4
iControl DC
7. When Ready is lighted, click Learn. The In Progress indicator lights when the Learn
button is clicked.
• If Manual learn type was selected, you are prompted to press and hold the iBox
Enable and Up buttons. The elevator will move up the hoistway at Inspection speed.
• You may click Abort at any time to abort the procedure. If the learn process is
aborted, the last saved complete set of values is retained.
8. The procedure is complete when the up normal limit switch (UNTD) is activated (if
Manual learn type, you are prompted to release the Enable and Up buttons) and Done
is lighted.
9. Set the iBox Learn switch to the OFF position.
10. Click the screen refresh button ( ) to update the learned floor height information.
11. On the Hoistway pane, verify that the learned floor heights appear accurate. Also check
the iBox Safety OK status. (Occasionally, the Final Limit Switch may open at the end of
a Learn run.)
For more information about the Floor Heights Learn procedure and the Status messages see
“Setup - Floor Heights - Learn Tab” on page 9-170.
Verifying One Floor Run Operation
The first step in verifying normal, one-floor run operation is to verify proper correction, run,
and stopping.
Verifying Correction, Run, and Stop
1. Arrange the elevator for empty car conditions.
2. On the Configuration > Pattern > Common tab, set Pattern scaling to 50%. This setting
allows the car to run at 50% of the commanded speed.
3. Move the car on Inspection to a location between floors, more than one foot away from a
landing so that no leveling sensors are engaged.
4. Place the car in Test mode (iBox Test switch ON). Set the iBox Fault Bypass switch to
ON.
5. Set the terminal limit switches to their default settings (View > Setup > Terminal
Switches) to allow the car to run.
6. Take the car out of Inspection operation (iBox Inspection switch in the NORM position).
The car will perform a Terminal Synchronization, using the learned position of the sen-
sor to update the current position reported by the position encoder.
If a Limits Switches Checksum Fault is generated when the car is removed from Inspection
operation, it will be necessary to set the terminal switches to default values before proceeding
(View > Setup > Terminal Switches tab). Perform the procedure shown in the Terminal Learn
message window titled “To default terminal switches, please do the following:”.
7. If the car corrects and stops properly, proceed to Initiating a One Floor Run later in this
section.
