iControl Ethernet Overview
5-13
5
iControl DC
LAN Hub/Switch
1.
Connect the group and car controll
ers and the iView PC to th
e LAN hub/switch as
shown in the illustration below and in the
MCE job prints. The job prints are the con-
trolling document. Use th
e blue Ethernet cables
provided.
Figure 5.9 Typical LAN (iView) Ethernet Connections
iCue (typical)*
1 1
1
1
iView PC
LAN Hub/Switch
LAN Hub
Po
wer Plug
*The iCue c
omputer in
your cabinet may be
different than the one
shown.
The
connection
for the LAN Hub/Swit
ch
is labeled LAN.
