MCE iControl User Manual

Reference
11-20 Manual # 42-02-7223
Summary by Group
Group #1 – Floors ( ) Machine Room Floor ( )
Group #1 -iBox Direct Connect Port
“= same as above
IP Subnet Gateway DNS
Any iBox 192.168.193.1 255.255.255.0 Blank or 0.0.0.0 Blank or 0.0.0.0
Any PC / Laptop 192.168.193.2 “ “ “
Group #1 -MCE System Network (Orange cables)
iBox – Car 1 192.168.192.1 “ “ “
iBox – Car 2 192.168.192.2 “ “ “
iBox – Car 3 192.168.192.3 “ “ “
iBox – Car 4 192.168.192.4 “ “ “
iBox – Car 5 192.168.192.5 “ “ “
iBox – Car 6 192.168.192.6 “ “ “
iBox – Car 7 192.168.192.7 “ “ “
iBox – Car 8 192.168.192.8 “ “ “
iBox – Car 9 192.168.192.9 “ “ “
iBox – Car 10 192.168.192.10 “ “ “
iBox – Car 11 192.168.192.11 “ “ “
iBox – Car 12 192.168.192.12 “ “ “
iBox – Car 13 192.168.192.13 “ “ “
iBox – Car 14 192.168.192.14 “ “ “
iBox – Car 15 192.168.192.15 “ “ “
iBox – Car 16 192.168.192.16 “ “ “
iBox – Car 17 192.168.192.17 “ “ “
iBox – Car 18 192.168.192.18 “ “ “
iBox – Car 19 192.168.192.19 “ “ “
iBox – Car 20 192.168.192.20 “ “ “
iCue
192.168.192.201
–
192.168.192.202
“““
Digi Hall Calls
UDP 3000-
3007
192.168.192.211
–
192.168.192.214
“““
