Adjusting Leveling and Final Stop
4-35
4
iControl DC
Ride Quality (System 12 SCR Drive)
If you are experiencing a ride sensation that is not exactly oscillation, but might be described as
a rough texture, it might be due to:
The encoder, attached to the motor shaft, may not be mounted securely, which may cause
bouncing or a slight variation in the speed feedback signal once every revolution. On a
geared machine, the coupling used between the tach or encoder and the motor can also be
a source of vibration. In both cases, the problem is observed by looking at the AC-coupled
encoder speed signal on iBox test point STP2 (with the Virtual Oscilloscope Test point 2
set to Speed Feedback). You may see the vibration frequency increase and decrease with
car speed. This is absolute proof of a mechanical problem with the speed transducer. Elec-
trically induced oscillations will be characterized by a frequency of oscillation that is con-
stant (does not change significantly with speed).
If the above steps do not resolve the vibration, the motor may not have been trimmed to
the machine properly. Use a dial indicator to check alignment of motor and machine.
Ride Quality (Quattro DC Drive)
If you are experiencing a ride sensation that is not exactly oscillation, but might be described as
a rough texture, it might be due to:
The speed control loop gains may not be adjusted properly. Please refer to the Magnetek
Quattro DC Drive Technical Manual for adjustment procedures.
The encoder, attached to the motor shaft, may not be mounted securely, which may cause
bouncing or a slight variation in the speed feedback signal once every revolution. On a
geared machine, the coupling used between the tach or encoder and the motor can also be
a source of vibration. In both cases, the problem is observed by looking at the AC-coupled
encoder speed signal on iBox test point STP2 (with the Virtual Oscilloscope Test point 2
set to Speed Feedback). You may see the vibration frequency increase and decrease with
car speed. This is absolute proof of a mechanical problem with the speed transducer. Elec-
trically induced oscillations will be characterized by a frequency of oscillation that is con-
stant (does not change significantly with speed).
If the above steps do not resolve the vibration, the motor may not have been trimmed to
the machine properly. Use a dial indicator to check alignment of motor and machine.
