Setting iBox Ethernet Port Addresses
7-9
7
iControl DC
Setting iBox Ethernet Port Addresses
The table below lists the factory default addresses TCP/IP addresses. The iBox 3 = PC port (PC
direct) is set to 192.168.193.001 and should not be changed.
*192.168.191.101 is typically used for the iView PC.
The default Subnet Mask for all ports is 255.255.255.000.
The default Gateway for the #1 (LAN or Peripheral Port) is 192.168.191.254.
The default Gateway for the #2 and #3 ports is 000.000.000.000.
You should not need to change the factory-set IP information. If you are having problems con-
necting to an iBox Ethernet port, refer to the following topic to verify and, if necessary, set IP
addresses.
Note
The Group ID setting in iView determines the iCue System IP address at which iCue will accept
messages. NO NOT set the Group ID to a setting other than 1 unless instructed to do so
by MCE. Group IDs other than 1 are reserved for future use and will cause group-to-car commu-
nication to fail. If you need advanced System addressing information, please contact MCE.
Table 7.3 System, LAN, & 3=PC TCP/IP Addresses
Hub Group
Group IP, Primary
& Backup
Car ID Car IP
System/Serial Hall
Call Bus 1 - 4
iView PC
System all 192.168.192.201-202 1-20 192.168.192.001-020 192.168.192.211-214
LAN A 192.168.191.201-202 1-20 192.168.191.001-020 192.168.192.101-200*
LAN B 192.168.191.203-204 1-20 192.168.191.021-040
LAN C 192.168.191.205-206 1-20 192.168.191.041-060
LAN D 192.168.191.207-208 1-20 192.168.191.061-080
LAN E 192.168.191.209-210 1-20 192.168.191.081-100
Port #3 = PC (iBox ONLY), NO HUB 192.168.193.001
