MCE iControl User Manual

Quattro DC Drive Parameters Quick Reference
11-27
11
iControl DC
Quattro DC Drive Parameters Quick Reference
This section includes quick reference information for the Quattro DC Drive parameters. Please
refer to the Quattro DC Elevator Drive Technical Manual provided with the drive for a detailed
explanation.
Table 11.6 Quattro DC Drive Parameters Quick Reference
Menu
Parameter
Units
Range Default Factory Setting
A1 CONTRACT CAR SPD
fpm 0.0 – 1500.0 100.0
*________
m/s 0.000 – 8.000 2.000
A1 CONTRACT MTR SPD RPM 30.0 – 3000.0 50.0
*________
A1 RESPONSE rad/sec 1.0 – 20.0 5.0
1.0
A1 INERTIA sec 0.25 – 50.00 2.00
2.00
A1 INNER LOOP XOVER rad/sec 0.1 – 20.0 2.0
1.0
A1 CURRENT LIMIT % 0.0 – 275.0 250.0
250.0
A1 GAIN REDUCE MULT % 10 – 100 100
100
A1 GAIN CHNG LEVEL % of rated spd 0.0 – 100.0 100.0
100.0
A1 TACH FILTER BW rad/sec 1 – 100 100
100
A1 TACH RATE GAIN none 0.0 – 30.0 0.0
0.0
A1 SPD PHASE MARGIN degrees 45 – 90 80
80
A1 RAMPED STOP TIME sec 0.00 – 2.50 0.20
0.20
A1 CONTACT FLT TIME sec 0.10 – 5.00 0.50
0.50
A1 BRAKE PICK TIME sec 0.00 – 5.00 1.00
1.00
A1 BRAKE HOLD TIME sec 0.00 – 5.00 0.50
0.50
A1 OVERSPEED LEVEL % of contract spd 90.0 – 150.0 115.0
115.0
A1 OVERSPEED TIME sec 0.00 – 9.99 0.10
1.00
A1 OVERSPEED MULT % 100.0 – 150.0 125.0
125.0
A1 ENCODER PULSES PPR 600 – 20000 5000
*________
A1 ENC RATIO MULT none 0.001 – 32.000 1.000
1.000
A1 SPD DEV LO LEVEL % of contract spd 0.1 – 20.0 10.0
10.0
A1 SPD DEV TIME sec 0.00 – 9.99 0.50
1.50
A1 SPD DEV HI LEVEL % of contract spd 0.0 – 99.9 10.0
10.0
A1 SPD COMMAND BIAS volts 0.00 – 6.00 0.00
0.00
A1 SPD COMMAND MULT none 0.90 – 5.00 1.00
1.00
A1 EXT TORQUE BIAS volts -6.00 – +6.00 0.00
0.00
A1 EXT TORQUE MULT none -10.00 – +10.00 1.00
1.00
A1 PRE TORQUE TIME sec 0.00 –10.00 0.00
???
A1 ZERO SPEED LEVEL % of contract spd 0.00 – 99.99 1.00
1.00
A1 ZERO SPEED TIME sec 0.00 – 9.99 0.10
0.10
A1 UP/DWN THRESHOLD % of contract spd 0.00 – 9.99 1.00
1.00
A1 ANA 1 OUT OFFSET % -99.9 – +99.9 0.0
0.0
A1 ANA 2 OUT OFFSET % -99.9 – +99.9 0.0
0.0
A1 ANA 1 OUT GAIN none 0.0 – 10.0 1.0
1.0
A1 ANA 2 OUT GAIN none 0.0 – 10.0 1.0
1.0
A1 FLT RESET DELAY sec 0 – 120 5
5
A1 FLT RESETS/HOUR faults 0 – 10 3
3
A1 UP TO SPD. LEVEL % of contract spd 0.00 – 110.00 90.00
90.00
A1 RUN DELAY TIMER sec 0.00 – 0.99 0.00
0.00
A1 AB ZERO SPD LEV % 0.00 – 2.00 1.00
1.00
A1 AB OFF DELAY sec 0.00 – 9.99 0.00
0.00
A1 CONTACTOR DO DLY sec 0.00 – 5.00 0.00
0.00
A1 TRQ LIM MSG DLY sec 0.00 – 10.00 0.50
0.50
