Serial COP Board Specifications
Each Serial COP board handles up to 24 call buttons or switches. If more inputs are required,
Serial COP boards are daisy-chained together.
• Each of the Serial COP board’s 24 I/O connections can be used as an input, an output or a
combined call input and output.
• Pluggable connections are provided for COP buttons and switches.
• Inputs can be 12 - 24 VDC (24V preferred).
• Outputs: 24V, 6W (maximum) lamps or 250mA LEDs recommended.
• Socketed, easily replaceable drivers protect the board from damage due to out-of-range
inputs.
• The initial Serial COP board (ICE-COP) communicates with the iLink ICE-CTP board
using an RJ-11 cable.
• Additional Serial COP boards (ICE-COP-X) are daisy-chained using RJ-11/RJ-45 cables.
• All Serial COP board I/O assignments are field configurable using the iView Configuration
> I/O Boards > Configuration tab. Please refer to “Configuration - I/O Boards” on page 9-
122. The signal types include:
•Car calls
•Car call enables (security)
• Enable overrides (security)
• Door controls
•Car status
• Position indicators
•Alarm I/O
•Load indicators
• Operating mode I/O including: Fire service, Attendant service, Independent service,
Flood operation, Inspection operation, Swing operation, Earthquake operation, Sab-
bath operation, Recall operation and CFSS (Commandeer for Special Service) opera-
tion.
Serial COP Installation
1. Mount the Serial COP boards in the car operating panel .
2. Connect the COP switches and lamps to the Serial COP board(s) using the pluggable
connectors. Refer to job print drawings - Cartop Details (-CTx).
3. Verify the COP board I/O assignments using the iView Configuration > I/O Boards >
Configuration tab.
ICE-COP Board Diagnostics The DIP switches and LEDs in the upper right corner of
the ICE-COP board provide diagnostic information. Please refer to “ICE-COP-2 Serial Car
Operating Panel Board” on page 6-82.
