Troubleshooting
6-40 Manual # 42-02-7223
Front Doors Stopped, FRONT DOORS STOPPED
Description: The Door Stop button or Emergency Stop switch was activated causing the doors to be pre-
vented from moving.
Car Reaction: The car is not allowed to move unless the doors are fully closed.
Troubleshooting: This condition can be cleared by activation of the Door Open button, Door Close button or if
the car goes into Inspection or Fire Service mode, provided that the Door Stop input is off.
Front DPM Open - GS Closed, F DPM OPEN-GS CLOSED
Description: The front door position monitoring contact is open while the gate switch is closed.
Car Reaction: None.
Troubleshooting: Check the front door position monitoring contact, gate switch and all related circuitry.
Front Hall Door Open Button Bypassed, FRONT HALL DOB BYP
Description: The front hall door open button has been continuously activated for a user-defined time (Door
open bypass timer) and is now bypassed in accordance with the user-defined setting (iView Controller >
Configuration > Car Operation > Doors)
Car Reaction: The front hall door open button is rendered inoperative.
Troubleshooting:
1. Check the corresponding input, Front Door - Hall Door Open Button: Normally low.
2. The operation of the hall door open button can also be restored by setting the Door open button bypass
option to off (unchecked) (iView Controller > Configuration > Car Operation > Doors)
Front Photo Eye Bypassed, FRONT PHOTO EYE BYP
Description: The front photo eye device has been continuously activated for a user-defined time and is now
bypassed in accordance to the user-defined setting. (iView/Car Operation/Passenger/Anti Nuisance.)
Car Reaction: The front photo eye device is rendered inoperative.
Troubleshooting:
1. To restore the operation of the photo eye device, check the corresponding input.
2. Related inputs: PhotoEyeFront: Normally low
Front Photo Eye Failure, FRONT PHOTO EYE FAIL
Description: This event is logged when the photo eye is continuously activated for a predetermined time (4
seconds) while the front doors are fully closed.
Car Reaction: The front photo eye is rendered inoperative.
Troubleshooting:
1. Check for abnormal blockage or failure of the front optical device.
2. Related inputs: FrontPhotoEye: Normally low
Front Safe Edge Bypassed, FRONT SAFE EDGE BYP
Description: The front door safe edge has been continuously activated for a user-defined time and is now
bypassed according to the user-defined setting. (iView Controller > Configuration > Car Operation > Doors)
Car Reaction: The front safe edge is rendered inoperative.
Troubleshooting:
1. Check the state of the front safe edge input.
2. Related inputs: SafeEdgeFront: Normally low
Front Safe Edge Failure, FRONT SAFE EDGE FAIL
Description: This event is logged when the front door safe edge is continuously activated for a predetermined
time (4 seconds) while the front doors are fully closed.
Car Reaction: The front door safe edge is rendered inoperative.
Troubleshooting:
1. Check for abnormal blockage or failure of the front door mechanical reopening device.
2. Related inputs:
FrontSafeEdge: Normally low
Table 6.3 iControl Messages
iControl Messages
