iControl Messages
6-47
6
iControl DC
Invalid Configuration Input DLAB, INVLD CNFG INPUT DLAB
Description: Door Lock Access Bottom. The safety system detected an input/safety setting difference when
cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Troubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Invalid Configuration Input DLAT, INVLD CNFG INPUT DLAT
Description: Door Lock Access Top. The safety system detected an input/safety setting difference when
cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Troubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Invalid Configuration Input DLMS, INVLD CNFG INPUT DLMS
Description: Door Lock Main String. The safety system detected an input/safety setting difference when
cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Troubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Invalid Configuration Input DLMS R, INV CNFG INPUT DLMS R
Description: Door Lock Main String Rear. The safety system detected an input/safety setting difference when
cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Troubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Invalid Configuration Input DPM, INVLD CNFG INPUT DPM
Description: Door Position Monitoring. The safety system detected an input/safety setting difference when
cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Troubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Invalid Configuration Input DPM_R, INV CNFG INPUT DPM_R
Description: Door Position Monitoring Rear. The safety system detected an input/safety setting difference
when cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Troubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Table 6.3 iControl Messages
