iControl Messages
6-59
6
iControl DC
Primary Fire Switch On, PRI FIRE SWITCH ON
Description: The primary fire switch is in the On position.
Car Reaction: Car will recall to Main fire recall floor, position its doors as directed on Car Operation/Fire/Mod-
ify/Fire Recall screen, and wait for activation of the in-car firefighter switch.
Troubleshooting: If in error, check the Primary Fire Recall Switch input.
QPRAM Device Error, QPRAM DEVICE ERROR
Description: Safety Processor A problem writing to QPRAM device.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Troubleshooting:
1. Replace QPRAM on Safety Processor A. Contact MCE.
Rear Auxiliary Door Open Button Bypassed, REAR AUX DOB BYP
Description: Rear auxiliary door open button continuously activated for user-defined time and is now
bypassed according to user defined setting (iView Controller > Configuration > Car Operation > Doors).
Car Reaction: The rear auxiliary door open button is rendered inoperative.
Troubleshooting:
1. Check corresponding input: Rear Auxiliary Door - Open Button (Normally low).
2. Operation of door open button can also be restored by setting Door open button bypass option to off
(unchecked) (iView Controller > Configuration > Car Operation > Doors).
Rear Door Close Fault, REAR DOOR CLOSE FAULT
Description: One or more rear door failures to close detected. Controller will attempt to close doors as
defined by user parameters (door close protection timer and number of attempts) before declaring fault.
(iView Controller > Configuration > Car Operation > Doors).
Car Reaction: Doors will reopen fully. All car calls canceled and car removes itself from hall call service (hall
calls assigned to car are canceled or reassigned to other cars). Doors may be closed using constant pressure
on rear door close button.
Troubleshooting:
1. Door closed status is determined by rear door close limit and rear door position monitor contact.
2. Check the wiring of these signals.
3. Check the door close protection timer and number of closing attempts on the Operation/Doors tab.
Rear Door Close Fault Recovery Failure, R DR CLS FLT REC FAIL
Description: Door Close Fault Recovery timer starts when Door Close Fault generated. When timer expires,
Door Close Fault cleared to allow doors to again attempt to close (see Rear Door Close Fault). Repeats the
number of times specified by Door Close Fault Recovery Attempts parameter. If doors have failed to close
when number of attempts equals recovery attempts, Rear Door Close Fault Recovery Failure generated.
Car Reaction: Car is not allowed to run until a mode change is detected or doors are successfully closed via
constant pressure on Door Close Button.
Troubleshooting:
1. Door closed status is determined by rear door close limit and rear door position monitor contact. Check
wiring of these signals.
2. Check door close protection timer and number of closing attempts on the Car Operation - Doors tab.
Rear Door Close Time-out
Description: Rear door failure to close detected. Controller will attempt to close doors for period of time
defined by Closing protection timer (Door Motor Protection Timers). If timer elapses prior to doors closing
fully, this event is generated.
Car Reaction: Doors reopen fully and again attempt to close.
Troubleshooting:
1. Door closed status determined by rear door close limit and rear door position monitor contact
2. Check the wiring of these signals.
3. Check the Closing protection timer (iView Controller > Configuration > Car Operation > Doors).
Table 6.3 iControl Messages
iControl Messages
