iControl Messages
6-61
6
iControl DC
Rear DPM Open-GS Closed, R DPM OPEN-GS CLOSED
Description: The rear door position monitoring contact is open while the gate switch is closed.
Car Reaction: None.
Troubleshooting: Check the rear door position monitoring contact, gate switch and all related circuitry.
Rear Hall Door Open Button Bypassed, REAR HALL DOB BYP
Description: The rear hall door open button has been continuously activated for a user-defined time (Door
open bypass timer) and is now bypassed in accordance with the user-defined setting (iView Controller >
Configuration > Car Operation > Doors).
Car Reaction: The rear hall door open button is rendered inoperative.
Troubleshooting:
1. Check the corresponding input, Rear Door - Hall Door Open Button: Normally low.
2. The operation of the hall door open button can also be restored by setting the Door open button bypass
option to off (unchecked) (iView Controller > Configuration > Car Operation > Doors).
Rear Photo Eye Bypassed, REAR PHOTO EYE BYP
Description: The rear photo eye device has been continuously activated for a user-defined time and is now
bypassed in accordance to the user-defined setting. (iView/Car Operation/Passenger/Anti Nuisance.)
Car Reaction: The rear photo eye device is rendered inoperative.
Troubleshooting:
1. To restore the operation of the photo eye device, check the corresponding input.
2. Related inputs:
PhotoEyeRear: Normally low.
Rear Photo Eye Failure, REAR PHOTO EYE FAIL
Description: This event is logged when the photo eye is continuously activated for a predetermined time (4
seconds) while the rear doors are fully closed.
Car Reaction: The rear photo eye is rendered inoperative.
Troubleshooting:
1. Check for abnormal blockage or failure of the rear optical device.
2. Related inputs:
RearPhotoEye: Normally low.
Rear Safe Edge Bypassed, REAR SAFE EDGE BYP
Description: The rear door safe edge has been continuously activated for a user-defined time and is now
bypassed according to the user-defined setting. (iView Controller > Configuration > Car Operation > Doors).
Car Reaction: The rear safe edge is rendered inoperative.
Troubleshooting:
1. Check the state of the rear safe edge input.
2. Related inputs:
SafeEdgeRear: Normally low.
Rear Safe Edge Failure, REAR SAFE EDGE FAIL
Description: This event is logged when the rear door safe edge is continuously activated for a predetermined
time (4 seconds) while the rear doors are fully closed.
Car Reaction: The rear door safe edge is rendered inoperative.
Troubleshooting:
1. Check for abnormal blockage or failure of the rear door mechanical reopening device.
2. Related inputs:
RearSafeEdge: Normally low.
Receive Sys Params
Description: Indicates that this controller is receiving system parameters from the Central or Local / Dis-
patcher. (DO NOT RESET THE CONTROLLER).
Table 6.3 iControl Messages
