Troubleshooting
6-92 Manual # 42-02-7223
Table 6.11 IFIELD-MODULE Indicators on the ICE-FML Board
Indicators Description
+15 ISO OK LED indicator for isolated +15V power supply, measured with respect to isolated
Ground, GND-ISO. Normally ON. Turns OFF when module loses +15 ISO voltage.
F. BAD LED indicator for AC input on FMX1 and FMX2 terminals (on FMP board). Normally
ON. Turns OFF when any input side AC fuse opens.
+15 OK LED indicator for +15V power supply, measured with respect to Ground. Normally
ON. Turns OFF when module looses +15V.
HI TEMP LED turns ON to indicate high temperature on the heat sink. Normally OFF. Turns
ON when the temperature of the main IGBT raises above 85
o
C (185
o
F).
IGBT FLT LED turns ON to indicate that the AUX IGBT has failed open.
Table 6.12 IFIELD MODULE Terminals on the ICE-FML Board
Terminal Description
1 1 BUS: AC input supply to the ICE-FML Board.
2 2B BUS: AC input supply to the ICE-FML Board.
FAN 1 (not used) Terminals for connecting an external fan.
FAN 2 (not used) Terminals for connecting an external fan.
TEMP 1 (not used) Terminals for connecting an external temperature sensor.
TEMP 2 (not used) Terminals for connecting an external temperature sensor.
