Controller Cabinet Installation
2-9
2
iControl DC
Figure 2.1 Cable Access
PC boards can be easily damaged by electrostatic dis-
charge (ESD). Use a properly grounded wrist strap or
other static protection when handling, touching, or
making connections to PC boards.
System 12 SCR
Drive
(Note: Quattro
DC Drive is
supplied in a
separate cabinet)
Input / Output
boards
M
Contactor
Resistors
Wiring Trough - (field wiring goes here)
Preferred cable access hole locations
iPower box
