Configuration - Car Operation
9-89
9
iControl DC
Status
• Shuttle service ON: LED is lighted when Shuttle service is On.
• Activate / Deactivate button: Software command used to turn Shuttle service On or Off.
Shuttle Floors and Car Call Disposition
• Cancel existing calls that are no longer eligible: Specifies that any calls that become ineligi-
ble as a result of switching to the Shuttle Floors eligibility map will be canceled.
• Use current eligibility: If enabled, Shuttle service will use the car call eligibilities specified
in the active car call configuration. Otherwise the “Shuttle Floors” map determines car call
eligibilities during Shuttle service operation.
• Shuttle Floors: Allows the user to create an alternate car call eligibility map to be used dur-
ing Shuttle service operation.
Home Floor Parking Permission
• No park: If no demand exists after the car completes a Shuttle service call, the car will
remain at the floor.
• Park - At floor: If no demand exists after the car completes a Shuttle service call, the car
will proceed to the specified floor and park.
• Front / Rear door time: Use the
“Edit” button to display the “Door
Timers” dialog and specify the
door behavior to be used when the
car parks. The options are:
•Closed
•Open
• Open for X seconds.
Home floor doors close when When the car is parked at the home floor, the doors
are closed when the conditions of any of the following (that are checked) are met.
• Door Close Timer: The doors are closed when the door close timer expires. The timer
starts when the first car call is registered.
• Number of registered car calls: The doors are closed when the number of registered car
calls reaches this value.
• Door close button pressed: If calls are registered, momentary activation of the door close
button causes the doors to close.
• Heavy load status reached: The doors are closed when the car reaches heavy load status.
