MCE iControl User Manual

iBox Field Connections
11-9
11
iControl DC
LIMITS
UNTD Up Normal Limit Direction switch input. 110 VDC = input on/switch
closed. 0 VDC = input off/switch open.
UNT5 Up Slowdown Limit switch #5 input. 110 VDC = input on/switch closed.
0 VDC = input off/switch open.
UNT4 Up Slowdown Limit switch #4 input. 110 VDC = input on/switch closed.
0 VDC = input off/switch open.
UNT3 Up Slowdown Limit switch #3 input. 110 VDC = input on/switch closed.
0 VDC = input off/switch open.
UNT2 Up Slowdown Limit switch #2 input. 110 VDC = input on/switch closed.
0 VDC = input off/switch open.
UETS Up Emergency Terminal Limit switch input. 110 VDC = input on/switch
closed. 0 VDC = input off/switch open.
UNT1 Up Slowdown Limit switch #1 input. 110 VDC = input on/switch closed.
0 VDC = input off/switch open.
DNT1 Down Slowdown Limit switch #1 input. 110 VDC = input on/switch
closed. 0 VDC = input off/switch open.
DETS Down Emergency Terminal Limit switch input. 110 VDC = input on/
switch closed. 0 VDC = input off/switch open.
DNT2 Down Slowdown Limit switch #2 input. 110 VDC = input on/switch
closed. 0 VDC = input off/switch open.
DNT3 Down Slowdown Limit switch #3 input. 110 VDC = input on/switch
closed. 0 VDC = input off/switch open.
DNT4 Down Slowdown Limit switch #4 input. 110 VDC = input on/switch
closed. 0 VDC = input off/switch open.
DNT5 Down Slowdown Limit switch #5 input. 110 VDC = input on/switch
closed. 0 VDC = input off/switch open.
DNTD Down Normal Limit Direction switch input. 110 VDC = input on/switch
closed. 0 VDC = input off/switch open.
Table 11.3 iBox Field Connections
Source Connection Signal Description
