iBox Field Connections
11-13
11
iControl DC
COMMON
1 Common Bus connections. 0 V
1 Common Bus connections. 0 V
1 Common Bus connections. 0 V
1 Common Bus connections. 0 V
120 VAC
2 PI 120 VAC. Fused, 2PI.
2 PI 120 VAC. Fused, 2PI.
2 120 VAC. Fused, F2.
2 120 VAC. Fused, F2.
110 VDC
3 HA 110 VDC. Fused, F3HA.
3 HA 110 VDC. Fused, F3HA.
3 110 VDC. Fused, F3.
3 110 VDC. Fused, F3.
Table 11.4 Expansion Board Connections
Board Connection Signal Description
MOR Out 1 - Out 32 The MOR (Multiple Output Relay) board provides 32 outputs customers
may use as needed for the particular job. Typical uses include activat-
ing chimes, buzzers, lights, etc. Each MOR board is configured accord-
ing to the job survey for a particular job before the system is shipped.
MOR boards may be installed in the iControl cabinet, in the iLink cartop
box, or in the iCentral cabinet (for elevator group controller use). Out-
put selection instructions are transmitted serially to the board. The 32
outputs are divided into five groups (1-4, 5-8, 9-16, 17-24, and 25-
32). According to need, each group can be connected to provide the
required output. Specific connections and output values are specified in
the job prints.
MIAC In 1 - In 32 The MIAC (Multiple Input AC) board provides 32 inputs customers may
use as needed for the particular job. MIAC boards may be installed in
the iControl cabinet, in the iLink cartop box, or in the iCentral cabinet
(for elevator group controller use). Typical uses include car call but-
tons, operating mode switches, etc. Specific connections are detailed in
the job prints. Please refer to “Input Signal Groups” on page 9-128.
SF
Serial Fixture
CAR 1 Common connection. 0V.
CAR +24 +24 VDC power to serial fixtures.
CAR CDATA Serial data stream to fixtures.
HALL 1 Common connection. 0V.
HALL +24 +24 VDC power to serial fixtures.
HALL HDATA Serial data stream to fixtures.
Table 11.3 iBox Field Connections
Source Connection Signal Description
