8-154 Phaser 7500 Printer Service Manual
Service Parts Disassembly
5. Remove the Front E-rings that secure the Retract Shaft Assembly.
6. Shift the 3 Sleeve Bearings to remove the Retract Shaft Assembly.
s7500-217
Make sure the flag is
out of the sensor
