8-184 Phaser 7500 Printer Service Manual
Service Parts Disassembly
Replacement Note
1. Make sure the Spring is installed with the large area of the Actuator is
positioned downward towards the tray.
2. Make sure the Pipe ACT Spring is installed over the Spring.
s7500-522
View A
A
Spring
Full Stack Actuator
s7500-523
