Preface: About This Guide
• Virtex-5 FPGA Configuration Guide
This all-encompassing configuration guide includes chapters on configuration
interfaces (serial and SelectMAP), bitstream encryption, Boundary-Scan and JTAG
configuration, reconfiguration techniques, and readback through the SelectMAP and
JTAG interfaces.
• Virtex-5 FPGA System Monitor User Guide
The System Monitor functionality available in all the Virtex-5 devices is outlined in
this guide.
• Virtex-5 FPGA Packaging and Pinout Specification
This specification includes the tables for device/package combinations and maximum
I/Os, pin definitions, pinout tables, pinout diagrams, mechanical drawings, and
thermal specifications.
• Virtex-5 FPGA PCB Designer’s Guide
This guide provides information on PCB design for Virtex-5 devices, with a focus on
strategies for making design decisions at the PCB and interface level.
Additional Support Resources
To find additional documentation, see the Xilinx website at:
http://www.xilinx.com/support/documentation/index.htm
.
To search the Answer Database of silicon, software, and IP questions and answers, or to
create a technical support WebCase, see the Xilinx website at:
http://www.xilinx.com/support
.
Typographical Conventions
This document uses the following typographical conventions. An example illustrates each
convention.
Convention Meaning or Use Example
Italic font
References to other documents
See the Virtex-5 FPGA Configuration
Guide for more information.
Emphasis in text
The address (F) is asserted after
clock event 2.
