Virtex-5 FPGA User Guide www.xilinx.com 317
UG190 (v5.0) June 19, 2009
Chapter 7
SelectIO Logic Resources
Introduction
This chapter describes the logic directly behind the I/O drivers and receivers covered in
Chapter 6, “SelectIO Resources.”
Virtex-5 FPGAs contain all of the basic I/O logic resources from Virtex-II/Virtex-II Pro
FPGAs. These resources include the following:
• Combinatorial input/output
• 3-state output control
• Registered input/output
• Registered 3-state output control
• Double-Data-Rate (DDR) input/output
• DDR output 3-state control
In addition, Virtex-5 FPGAs implement the following architectural features that are also
supported in Virtex-4 FPGAs:
• IODELAY provides users control of an adjustable, fine-resolution delay element
• SAME_EDGE output DDR mode
• SAME_EDGE and SAME_EDGE_PIPELINED input DDR mode
