306 www.xilinx.com Virtex-5 FPGA User Guide
UG190 (v5.0) June 19, 2009
Chapter 6: SelectIO Resources
Nominal PCB Specifications
The nominal SSO table (Table 6-40) contains SSO limits for cases where the PCB
parameters meet the following requirements.
Note:
In cases where PCB parameters do not meet all requirements listed below, the Virtex-5 FPGA
SSO Calculator must be used to determine the SSO limit, according to the physical factors of the
unique PCB.
PCB Construction
V
CCO
and GND vias should have a drill diameter no less than 11 mils (279 µ).
Total board thickness must be no greater than 62 mils (1575 µ).
Signal Return Current Management
Traces must be referenced to a plane on an adjacent PCB layer.
The reference plane must be either GND or the V
CCO
associated with the output
driver.
The reference layer must remain uninterrupted for its full length from device to
device.
Load Traces
All IOB output buffers must drive controlled impedance traces with characteristic
impedance of 50Ω ± 10%.
Total capacitive loading at the far end of the trace (input capacitance of receiving
device) must be no more than 10 pF.
Power Distribution System Design
Designed according to the Virtex-5 FPGA PCB Designers Guide.
Decoupling capacitors per the device guideline
Approved solder land patterns
V
CCO
and GND planes cannot be separated by more than 5.0 mils (152 µ)
