9.2.3 Accessing the MPU using the alias registers

You can optimize the loading speed of the MPU registers using register aliasing. There

are three sets of Nested Vectored Interrupt Controller (NVIC) alias registers. These are

described in NVIC register descriptions on page 8-7.

The aliases access the registers in exactly the same way, and they exist to enable the use

of sequential writes (STM) to update between one and four regions. This is used when

disable/change/enable is not required.

b01110 32KB

b01111 64KB

b10000 128KB

b10001 256KB

b10010 512KB

b10011 1MB

b10100 2MB

b10101 4MB

b10110 8MB

b10111 16MB

b11000 32MB

b11001 64MB

b11010 128MB

b11011 256MB

b11100 512MB

b11101 1GB

b11110 2GB

b11111 4GB

Table 9-7 MPU protection region size field (continued)
