ARM Cortex-M3 User Manual

Embedded Trace Macrocell
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 14-17
Unrestricted Access Non-Confidential
Trace Start/Stop Resource Control - 0xE0041018 No -
TraceEnable Event Write only
0xE0041020 Yes Describes the TraceEnable
enabling event.
[16:14] Boolean function.
[13:7] Resource A.
[6:0] Resource B.
See ETM Event resources on
page 14-22.
TraceEnable Control 1 Write only
0xE0041024 Yes For a description, see page 14-21.
TraceEnable Control 2 Write only
0xE004101C No -
FIFOFULL Region Write only
0xE0041028 No If enabled, FifoFull logic is always
active.
FIFOFULL Level Read/write
0xE004102C Yes The number of bytes left in the
FIFO, below which the
FIFOFULL signal is asserted to
stall the core. Bit [7] of the ETM
Control Register is used to enable
the FIFOFULL output.
ViewData - 0xE0041030 -
0xE004103C
No -
Address Comparators -
0xE0041040 -
0xE004113C
No -
Counters -
0xE0041140 -
0xE004157C
No -
Sequencer -
0xE0041180 -
0xE0041194 ,
0xE0041198
No -
External Outputs -
0xE00411A0 -
0xE00411AC
No -
CID Comparators - 0xE00411B0 -
0xE00411BC
No -
Implementation specific -
0xE00411C0 -
0xE00411DC
No All RAZ. Ignore writes.
Table 14-9 ETM registers (continued)
Name Type Address Present Description
