ARM Cortex-M3 User Manual

Embedded Trace Macrocell
14-18 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Synchronization Frequency Read only 0xE00411E0 Yes Reads as 0x00000400 .
ETM ID Read only
0xE00411E4 Yes For a description, see page 14-21.
Configuration Code Extension Read only
0xE00411E8 Yes For a description, see page 14-21.
Extended External Input Selector -
0xE00411EC No No extended external inputs
implemented.
TraceEnable Start/Stop Embedded ICE Read/write
0xE00411F0 Yes Bits [19:16] configure DWT
comparator inputs to use as stop
resources. Bits [3:0] configure
DWT Comparator inputs to use as
start resources.
Embedded ICE Behavior Control - 0xE00411F4 No Embedded ICE (DWT
comparator) inputs use the default
behavior.
CoreSight Trace ID Read/write
0xE0041200 Yes Implemented as normal.
Values of
0x00 , 0x70-0x7F are
reserved and must not be used
when the ETM is active.
OS Save/Restore -
0xE0041304 -
0xE0041308
No OS Save/Restore not
implemented. RAZ, ignore writes.
Power Down Status Register Read only
0xE0041314 Yes For a description, see page 14-22.
ITMISCIN Read only
0xE0041EE0 Yes Sets [1:0] to EXTIN[1:0], [4] to
COREHALT.
ITTRIGOUT Write only
0xE0041EE8 Yes Sets [0] to TRIGGER.
ITATBCTR2 Read only
0xE0041EF0 Yes Sets [0] to ATREADY.
ITATBCTR0 Write only
0xE0041EF8 Yes Sets [0] to ATVALID.
Integration Mode Control Read/write
0xE0041F00 Yes Implemented as normal.
Claim Tag Read/write
0xE0041FA0 -
0xE0041FA4
Yes Implements the 4-bit claim tag.
Lock Access Write only 0xE0041FB0 -
0xE0041FB4
Yes Implemented as normal.
Lock Status Read only
0xE0041Fb4 Yes Implemented as normal.
Table 14-9 ETM registers (continued)
Name Type Address Present Description
