ARM Cortex-M3 User Manual

System Control
3-14 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Sequencer Read/write 0xE0041180- 0xE0041194, 0xE0041198 No
External Outputs Write-only
0xE00411A0-0xE00411AC No
CID Comparators Write-only
0xE00411B0-0xE00411BC No
Implementation specific Write-only
0xE00411C0-0xE00411DC No
Synchronization Frequency Read-only
0xE00411E0 Yes
ETM ID Read-only
0xE00411E4 Yes
Configuration Code Extension Read-only
0xE00411E8 Yes
Extended External Input Selector Write-only
0xE00411EC No
TraceEnable Start/Stop Embedded ICE Read/write
0xE00411F0 Yes
Embedded ICE Behavior Control Write-only
0xE00411F4 No
CoreSight Trace ID Read/write
0xE0041200 Yes
OS Save/Restore Write-only
0xE0041304-0xE0041308 No
ITMISCIN Read-only
0xE0041EE0 Yes
ITTRIGOUT Write-only
0xE0041EE8 Yes
ITATBCTR2 Read-only
0xE0041EF0 Yes
ITATBCTR0 Write-only
0xE0041EF8 Yes
Integration Mode Control Read/write
0xE0041F00 Yes
Claim Tag Read/write
0xE0041FA0-0xE0041FA4 Yes
Lock Access Write-only
0xE0041FB0-0xE0041FB4 Yes
Authentication Status Read-only
0xE0041FB8 Yes
Device Type Read-only
0xE0040FCC Yes
Peripheral ID 4 Read-only
0xE0041FD0 Yes
Peripheral ID 5 Read-only
0xE0041FD4 Yes
Peripheral ID 6 Read-only
0xE0041FD8 Yes
Peripheral ID 7 Read-only
0xE0041FDC Yes
Table 3-10 ETM registers (continued)
Name Type Address Present
