System Control

Unrestricted Access Non-Confidential

Peripheral ID 0 Read-only

0xE0041FE0

Yes

Peripheral ID 1 Read-only

0xE0041FE4

Yes

Peripheral ID 2 Read-only

0xE0041FE8

Yes

Peripheral ID 3 Read-only

0xE0041FEC

Yes

Component ID 0 Read-only

0xE0041FF0

Yes

Component ID 1 Read-only

0xE0041FF4

Yes

Component ID 2 Read-only

0xE0041FF8

Yes

Component ID 3 Read-only

0xE0041FFC

Yes

Table 3-10 ETM registers (continued)

Name Type Address Present
