Table 54 CRIMP TOOLS FOR LARGE BACT12AC TERMINAL LUGS (Continued)
Crimp Barrel
Size
Insulation
Color
Crimp Tool
Basic Unit Holder Head Die Set
6 Blue
1213875-1
(Battery powered)
- - 1490598-1
1901343-1
(Battery powered)
- - 1901007-1
59974-1 - - 47821
Power Pump
- 69051 47821
- 69061 47821
- ST970-12 47821
4 Yellow
1213875-1
(Battery powered)
- - 1490599-1
59974-1 - - 47822
Power Pump
- 69051 47822
- 69061 47822
- ST970-12 47822
2 Red
1213875-1
(Battery powered)
- - 1490406-1
59974-1 - - 47823
Power Pump
- 69051 47823
- 69061 47823
- ST970-12 47823
1/0 Blue
1213875-1
(Battery powered)
- - 1490700-1
Power Pump
- 58422-1 47824
- 69066 47824
- PPFC-1H 47824
2/0 Yellow Power Pump
- 58422-1 47825
- 69066 47825
- PPFC-1H 47825
4/0 Blue Power Pump
- 58422-1 47918
- 69066 47918
NOTE: Refer to Table 40 for the part numbers of the recommended Power Pumps.
NOTE: Refer to Subject 20-30-22 for the assembly of a terminal lug with a conductor that is smaller
than the crimp barrel size of the terminal lug.
(1) Make a selection of a terminal lug from Table 3.
NOTE: For the selection of the terminal, use:
• The crimp barrel size, if one wire is to be terminated
