Table 58 CRIMP TOOLS FOR BACT12E UPRIGHT TERMINAL LUGS (Continued)
Crimp Barrel
Size
Crimp Tool
Basic Unit Head
Die
Primary Secondary Cavity
12 - 10
314700-1 - 314656-1 - 12-10
46447 - - - -
49935 - - - -
59461 - - - -
M8ND - N10HT - -
Power Pump Y34A V8L 34PL -
Y10MRF-4 - - - -
Y10MRF-5 - - - -
Y8ND - N10HT - -
8
M8ND - N8CT - -
MR8-5 - - - -
Power Pump
13642M ST2354-5 11732 -
69069 47321 47322 -
BDHD1 DV8L-1 Y29PL -
TBHD1 ST2354-5 11732 -
TBM12 ST2354-5 11732 -
Y29B DV8L-1 Y29PL -
Y8ND - N8CT - -
6 Power Pump
13642M ST2354-6 - -
69069 47321 47322 -
BDHD1 DV6L Y29PL -
TBHD1 ST2354-6 - -
TBM12 ST2354-6 - -
Y29B DV8L-1 Y29PL -
4 Power Pump
13642 ST2354-2 11734 -
13642M ST2354-2 11734 -
69069 47321 47322 -
BDHD1 DV4L Y29PL -
TBHD1 ST2354-2 11734 -
TBM12 ST2354-2 11734 -
Y29B DV4L Y29PL -
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
