Table 58 CRIMP TOOLS FOR BACT12E UPRIGHT TERMINAL LUGS (Continued)
Crimp Barrel
Size
Crimp Tool
Basic Unit Head
Die
Primary Secondary Cavity
2 Power Pump
13642M ST2354-1 - -
69069 47321 47322 -
BDHD1 DV2L Y29PL -
TBHD1 ST2354-1 - -
TBM12 ST2354-1 - -
Y29B DV2L Y29PL -
1/0 Power Pump
13642 11738 11737 -
13642M 11738 11737 -
BDHD1 DV25L Y29PR -
TBHD1 11738 - -
TBM12 11738 11737 -
Y29B DV25L Y29PR -
2/0 Power Pump
13642M 11739 11737 -
BDHD1 DV26L Y29PR -
TBHD1 11739 - -
TBM12 11739 11737 -
Y29B DV26L Y29PR -
3/0 Power Pump
13642M ST2354-3 - -
BDHD1 DV27L Y29PR -
TBHD1 ST2354-3 - -
TBM12 ST2354-3 - -
Y29B DV27L Y29PR -
4/0 Power Pump
BDHD1 DV28L Y29PR -
Y29B DV28L Y29PR -
Table 59
INSULATION REMOVAL LENGTHS FOR BACTA12E UPRIGHT TERMINAL LUGS
Crimp Barrel Size
Insulation Removal Length
(inch)
Stud Hole Size
22-18 0.25 10
16-14 0.25 10
12-10 0.43
10
1/4
8 0.43 10
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 76
Feb 15/2016D6-54446
