Table 64 INDENTER TYPE CRIMP TOOLS FOR LARGE BACT12M AND 280U0010-1 TERMINAL LUGS
(Continued)
Crimp
Barrel Size
Crimp Tool
Basic Unit Head Adapter Nest Indenter Special Instructions
1/0
1213875-1
(Battery powered)
- - 1490413-5 1490414-3 -
59973-1 - - 48132 48131 -
69020 - - 48132 48131 -
BAT35 - Y35P3 UV25L Y34PA
Use for Burndy terminal
lugs only
Power Pump
BDHD1 - DV25L Y29PR
Use for Burndy terminal
lugs only
Y29B - DV25L Y29PR
Use for Burndy terminal
lugs only
Y35BH Y35P3 UV25L Y34PA
Use for Burndy terminal
lugs only
Y35 - Y35P3 UV25L Y34PA
Use for Burndy terminal
lugs only
2/0
1213875-1
(Battery powered)
- - 1490413-6 1490414-3 -
59973-1 - - 48133 48131 -
69020 - - 48133 48131 -
BAT35 - Y35P3 UV26L Y34PA
Use for Burndy terminal
lugs only
Power Pump
BDHD1 - DV26L Y29PR
Use for Burndy terminal
lugs only
Y29B - DV26L Y29PR
Use for Burndy terminal
lugs only
Y35BH Y35P3 UV26L Y34PA
Use for Burndy terminal
lugs only
Y35 - Y35P3 UV26L Y34PA
Use for Burndy terminal
lugs only
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 88
Oct 15/2017D6-54446
