Table 64 INDENTER TYPE CRIMP TOOLS FOR LARGE BACT12M AND 280U0010-1 TERMINAL LUGS
(Continued)
Crimp
Barrel Size
Crimp Tool
Basic Unit Head Adapter Nest Indenter Special Instructions
3/0
1213875-1
(Battery powered)
- - 1490413-7 1490414-3 -
59973-1 - - 48134 48131 -
69020 - - 48134 48131 -
BAT35 - Y35P3 UV27L Y34PA
Use for Burndy terminal
lugs only
Power Pump
BDHD1 - DV27L Y29PR
Use for Burndy terminal
lugs only
Y29B - DV27L Y29PR
Use for Burndy terminal
lugs only
Y35BH Y35P3 UV27L Y34PA
Use for Burndy terminal
lugs only
Y35 - Y35P3 UV27L Y34PA
Use for Burndy terminal
lugs only
4/0
1213875-1
(Battery powered)
- - 1490413-8 1490414-3 -
- - UV28L Y34PA -
59973-1 - - 300430 48131 -
69020 - - 300430 48131 -
-
BDHD1 - DV28L Y29PR
Use for Burndy terminal
lugs only
Y29B - DV28L Y29PR
Use for Burndy terminal
lugs only
Y35 - UV28L Y34PA -
Y35BH - UV28L Y34PA -
NOTE: Refer to Table 40 for the part numbers of the recommended Power Pumps.
