Table 65
HEX TYPE CRIMP TOOLS FOR LARGE BACT12M AND 280U0010-1 TERMINAL LUGS
Crimp Barrel Size
Crimp Tool
Basic Unit Head Adapter
Die Set
Primary Secondary
8 Power Pump
13642 - ST2354-5 11732
13642M - ST2354-5 11732
BDHD1 - ST2354B-5 -
TBHD1 - ST2354-5 11732
TBM12 TBM12D-AR ST2354-5 11732
Y29B - ST2354B-5 -
6 Power Pump
13642 - ST2354-6 -
13642M - ST2354-6 -
BDHD1 - ST2354B-6 -
TBHD1 - ST2354-6 -
TBM12 TBM12D-AR ST2354-6 -
Y29B - ST2354B-6 -
4 Power Pump
13642 - ST2354-2 -
13642M - ST2354-2 -
BDHD1 - ST2354B-2 -
TBHD1 - ST2354-2 11734
TBM12 TBM12D-AR ST2354-2 11734
Y29B - ST2354B-2 -
2 Power Pump
13642 - ST2354-1 -
13642M - ST2354-1 -
BDHD1 - ST2354B-1 -
TBHD1 - ST2354-1 -
TBM12 TBM12D-AR ST2354-1 -
Y29B - ST2354B-1 -
1/0 Power Pump
13642 - 11738 11737
13642M - 11738 11737
TBHD1 - 11738 11737
TBM12 TBM12D-AR 11738 11737
2/0 Power Pump
13642 - 11739 -
13642M - 11739 -
TBHD1 - 11739 -
TBM12 TBM12D-AR 11739 -
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 90
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
