Table 65 HEX TYPE CRIMP TOOLS FOR LARGE BACT12M AND 280U0010-1 TERMINAL LUGS
(Continued)
Crimp Barrel Size
Crimp Tool
Basic Unit Head Adapter
Die Set
Primary Secondary
3/0 Power Pump
13642 - ST2354-16 ST2354-3
13642M - ST2354-16 ST2354-3
BDHD1 - ST2354B-3 -
TBHD1 - ST2354-16 ST2354-3
TBM12 TBM12D-AR ST2354-16 ST2354-3
Y29B - ST2354B-3 -
4/0 Power Pump
13642 - ST2354-13 -
13642M - ST2354-13 -
13642M - ST2354-16 ST2354-13
NOTE: Refer to Table 40 for the part numbers of the recommended Power Pumps.
NOTE: Refer to Subject 20-30-22 for the assembly of a terminal lug with a conductor that is smaller
than the crimp barrel size of the terminal lug.
(1) Make a selection of a terminal lug from Table 17.
NOTE: An AMP solid nickel terminal lug is a satisfactory alternative to a BACT12M terminal lug.
NOTE: For the selection of the terminal, use:
• The crimp barrel size, if one wire is to be terminated
• The CAU range, if more than one wire is to be terminated.
NOTE: Refer to Subject 20-30-22 if more than one wire is to be terminated.
(2) Make a selection of a crimp tool from:
• Table 63 for small BACT12M terminal lugs
• Table 64 or Table 65 for large BACT12M terminal lugs
(3) If the tool has an insulation crimp adjustment, set the position of the adjustment. Refer to
Paragraph 2.B.
Make sure to set the adjustment at position 2 for these wires:
• Champlain 24-00034 wire
• Champlain 24-00523 wire
• Filotex 85842 wire.
(4) If the crimp tool basic unit is a power pump, adjust the pressure to make it satisfactory for the
crimp tool head. Refer to Table 41.
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 91
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
