Table 73
CRIMP TOOLS FOR HEAVY DUTY YAV14 TERMINAL LUGS
Crimp Barrel Size
Crimp Tool
Basic Unit Die Set Die Cavity
22-18
M8ND N14HT 14
Y8ND N14HD 14
20-14
M8ND N14HT 14
Y8ND N14HT 14
16 - 14
M8ND N14HT 14
MR8-4 N14HT 14
MR8G98 N14HT 14
WT130 N14HT 14
WT1300 N14HT 14
Y8ND N14HT 14
Table 74
INSULATION REMOVAL LENGTH AND SPECIAL INSTRUCTIONS FOR YAV14G82 AND YAV14G88
TERMINAL LUGS
Crimp Barrel
Size
Part Number
Conductors in the Crimp
Barrel
Insulation
Removal Length
(inch)
Special Instructions
First Wire
(AWG)
Second
Wire
(AWG)
16-14
YAV14G82
14 - 0.25 ±0.03 -
16 - 0.25 ±0.03 -
18 20 0.25 ±0.03 -
18 18 0.25 ±0.03 -
18 - 0.50 ±0.03 Fold back the conductor
20 - 0.50 ±0.03 Fold back the conductor
YAV14G88
14 - 0.25 ±0.03 -
16 - 0.25 ±0.03 -
18 20 0.25 ±0.03 -
18 18 0.25 ±0.03 -
18 - 0.50 ±0.03 Fold back the conductor
20 - 0.50 ±0.03 Fold back the conductor
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 107
Feb 15/2020D6-54446
