Table 75
INSULATION REMOVAL LENGTH
Crimp Barrel Size
Insulation Removal Length
(inch)
Part Number
20-14 0.28 ±0.03
YAV14-H
YAV14-H1
22-18 0.28 ±0.03 YAV18-H
6 0.50 ±0.03 YAV6C-2L38-NK
4 0.50 ±0.03
YAV4C-2L38-NK
YAV4C-2L38-30-NK
YAV4CRS2NK
2 0.63 ±0.03 YAV2C-2L38-NK
1/0 0.69 ±0.03
YAV25-2L38-NK
YAV25RSNK
2/0 0.81 ±0.03
YAV26-2L38-NK
YAV26-2L38-30-NK
3/0 0.81 ±0.03
YAV27-2L38-NK
YAV27-2L38-30-NK
(1) Make a selection of a terminal lug from:
• Table 24 for dual hole terminal lugs
• Table 25 for upright terminal lugs
• Table 26 for heavy duty terminal lugs.
NOTE: For the selection of the terminal, use:
• The crimp barrel size, if one wire is to be terminated
• The CAU range, if more than one wire is to be terminated.
NOTE: Refer to Subject 20-30-22 if more than one wire is to be terminated.
(2) Make a selection of a crimp tool from:
• Table 70 or Table 71 for dual hole terminal lugs
• Table 72 for upright terminal lugs
• Table 73 for heavy duty terminal lugs.
(3) If the crimp tool basic unit is a power pump, adjust the pressure to make it satisfactory for the
crimp tool head. Refer to Table 41.
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 108
Feb 15/2020D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
