Table 79
CRIMP TOOLS FOR ROLLS-ROYCE TERMINAL LUGS
Terminal Lug Crimp Barrel Size
Crimp Tool
Basic Unit Die
1909156 20 - 16 574191-8 574191-1
2509293 22 - 16 574191-8 574191-1
Table 80
CRIMP TOOLS FOR THERMOCOUPLE TERMINAL LUGS
Terminal Lug
Crimp Barrel
Size
Crimp Tool
Basic Unit Setting Holder Head Nest Die
1-321897-0 22-16 46673
Insulation Grip
Setting 3
- - - -
1-321898-0 22-16 46673
Insulation Grip
Setting 3
- - - -
1387-3 - Y14MV - - - - -
1387-4 - Y14MV - - - - -
Table 81
CRIMP TOOLS FOR 69B40570-2 TERMINAL LUGS
Terminal Lug Wire Crimp Tool
Part Number
Crimp
Barrel Size
AWG
Quantity of
Wires in the
Crimp Barrel
Basic Unit Head
Die
Primary Secondary
69B40570-2 2/0
4 2
Power
Pump
13642M 11738 11737
1/0 1
Table 82
INSULATION REMOVAL LENGTH FOR THERMOCOUPLE AND 69B40570 TERMINAL LUGS
Terminal Lug Part Number
Insulation Removal Length
(inch)
1-321897-0 0.25 ±0.03
1-321898-0 0.25 ±0.03
1387-3 0.31 ±0.06
1387-4 0.31 ±0.06
69B40570-2 0.75 ±0.03
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 111
Oct 15/2017D6-54446
