Table 83
CRIMP TOOLS FOR OTHER TERMINAL LUGS
Terminal Lug
Crimp
Barrel Size
Crimp Tool
Basic Unit Setting Holder Head Nest Die
150456 20-16 574191-8 - - - - 574191-1
150471 22-16 574191-8 - - - - 574191-1
2-320561-3 16 59250 - - - - -
2-320561-4 14 59250 - - - - -
2-321670-2 6 Power Pump - - 69051 - 47821
2-321672-1 2 Power Pump - - 69051 - 47823
2-323914-2 24 59275 - - - - -
2-323916-3 24 59275 - - - - -
2-326875-4 24 59275 - - - - -
2-326875-5 24 59275 - - - - -
2-36149-3 22 59250 - - - - -
2-36149-4 20 59250 - - - - -
2-36149-5 18 59250 - - - - -
320381 16-14 59250 - - - - Blue
320634 12-10 69694-1 - - - - -
322215 1/0
MY28
Size 2 Flag
Terminal
- - - -
Y29BH - - - DV26LM1 Y29PA
322220 4/0
Power Pump - - 13642 - ST2354-13
Power Pump - - 13642M - ST2354-13
323067 12-10
314937-1 - - - - 314915-1
59461 - - - - -
PHRPU2 - - PHST-59461 - -
324111 4 Power Pump - - 69051 - 47822
324112 2 Power Pump - - 69051 - 47823
324113 1/0 Power Pump - - 69066 - 47824
324158 22-18
59250 - - - - -
69692-1 - - - - -
324915 12-10 59239-4 - - - - -
32456 22-18 59250 - - - - Red
328655 2 Power Pump - - 69051 - 47823
329636 24-20 59275 - - - - -
329951 26-22
59275 - - - - -
69692-1 - - - - -
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 112
Feb 15/2020D6-54446
