Table 116
CABLE TRIM DIMENSIONS
Cable Conductor
Trim Dimension
(inch)
Dimension Target Tolerance
A
C1
D1 0.28
±0.02D2 1.92
D3 2.20
C2
D1 0.28
±0.02D2 0.77
D3 1.05
B
C1
D1 0.28
±0.02D2 0.77
D3 1.05
C2
D1 0.28
±0.02D2 1.92
D3 2.20
H. Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit - One Class
2 Shielded Cable to One Class 2 Shielded Cable and One Unshielded Wire
Table 117
SPLICE KITS FOR ONE CLASS 2 SHIELDED CABLE TO ONE CLASS 2 SHIELDED CABLE AND ONE
CLASS 1 WIRE
Jacket Maximum
O.D.
Shield Minimum
O.D.
Conductor CAU Range Solder Shield Splice Kit
Minimum Maximum Part Number Supplier
0.15 0.08 3 15 D-150-0174 Tyco/Raychem
0.18 0.10 8 27 D-150-0175 Tyco/Raychem
0.34 0.19 19 67 D-150-0177 Tyco/Raychem
NOTE: The CAU of the shield of Cable B must be increased.
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
