Boeing 707 - Page 570

Table 15
BACS52N SPLICE CRIMP TOOLS
Splice
First Wire Second Wire Crimp Tool
Type Size
(AWG)
Type Size
(AWG)
Head Die Set
BACS52N-1 Aluminum 8 Copper 10
58422-1 68006
69066 68006
BACS52N-1A78 Aluminum 8 Copper 10
58422-1 68006
69066 68006
BACS52N-2 Aluminum 6 Copper 8
58422-1 68007
69066 68007
BACS52N-2A78 Aluminum 6 Copper 8
58422-1 68007
69066 68007
BACS52N-3 Aluminum 4 Copper 6
58422-1 68008
69066 68008
BACS52N-3A78 Aluminum 4 Copper 6
58422-1 68008
69066 68008
69066 68008
BACS52N-4 Aluminum 2 Copper 4
58422-1 68009
69066 68009
BACS52N-48 Aluminum 4 Copper 8
58422-1 68008
58422-1 68008-1
69066 68008-1
BACS52N-4A78 Aluminum 2 Copper 4
58422-1 68009
69066 68009
BACS52N-5 Aluminum 1/0 Copper 2
58422-1 68010
69066 68010
BACS52N-5A78 Aluminum 1/0 Copper 2
58422-1 68010
69066 68010
BACS52N-6
Aluminum 2/0 Copper 1/0 58422-1 68011-1
Aluminum 2/0 Aluminum 1/0 58422-1 68011-1
Aluminum 1/0 Copper 1/0 58422-1 68011-1
BACS52N-6A78 Aluminum 2/0 Copper 1/0 58422-1 68011-1
BACS52N-7 Aluminum 3/0 Copper 2/0 58422-1 59877-1
BACS52N-7A78 Aluminum 3/0 Copper 2/0 58422-1 59877-1
BACS52N-8 Aluminum 4/0 Copper 3/0 58422-1 314948-1
BACS52N-8A78 Aluminum 4/0 Copper 3/0 58422-1 314948-1
ASSEMBLY AND REPAIR OF THE AMP AND BACS52N COPALUM SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-13
Page 18
Oct 15/2017D6-54446
