Table 16
CRIMP TOOL POWER PUMPS
Power Pump Notes Supplier
122271-1 - AMP
69120-() - AMP
1804700-1 Can be used with AMP foot pedal 68284-1-3 AMP
Table 17
SATISFACTORY PRESSURES FOR THE OPERATION OF CRIMP HEADS
Crimp Head
Pressure
(psi)
Minimum Maximum
58422-1 8000 8400
69066 8000 8400
PPFC-1H 8500 9000
1752787-1 9500 10000
(1) Make a selection of an AMP splice crimp tool from Table 14 and BACS52N splice crimp tool from
Table 15.
CAUTION
COPALUM SPLICES MUST BE CRIMPED WITH THE SPECIFIED TOOLS
FOR THE SPLICE. IF THE SPECIFIED TOOLS ARE NOT USED,
UNSATISFACTORY PERFORMANCE OF THE SPLICE CAN OCCUR.
(2) Make a selection of a power pump from Table 16.
Make sure that the power pump pressure is satisfactory for the crimp tool head. Refer to Table
17.
WARNING
IF THE PRESSURE OF THE POWER PUMP IS MORE THAN THE
MAXIMUM PRESSURE PERMITTED FOR THE CRIMP TOOL HEAD, AN
INJURY TO PERSONNEL CAN OCCUR.
CAUTION
IF THE PRESSURE OF THE POWER PUMP IS MORE THAN THE
MAXIMUM PRESSURE PERMITTED FOR THE CRIMP TOOL HEAD,
DAMAGE TO THE CRIMP HEAD CAN OCCUR.
ASSEMBLY AND REPAIR OF THE AMP AND BACS52N COPALUM SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-13
Page 19
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
