Table 19 AMP SPLICES THAT MUST HAVE LAYERS OF BUILDUP TAPE (Continued)
Splice
Wire Size
(AWG)
Layers of Buildup Tape
Splice End A Splice End B
277158-1
6 6 Three Layers
6 4 Three Layers
4 4 -
277159-1
4 4 -
4 2 Three Layers
2 2 -
277160-1
2 2 -
2 1/0 -
1/0 1/0 -
277161-1
1/0 1/0 -
1/0 2/0 -
2/0 2/0 -
277162-1
2/0 2/0 -
2/0 3/0 -
3/0 3/0 -
277163-1 4 1/0 Three Layers
277164-1 4 8 Three Layers
277165-1 4 4 -
277168-1 3/0 1/0 -
Table 20
BACS52N SPLICES THAT MUST HAVE LAYERS OF BUILDUP TAPE
Splice
Wire Size(AWG)
Layers of Tape
First Splice End Second Splice End
BACS52N-1 8 10 3 layers minimum
BACS52N-1A78 8 10 3 layers minimum
BACS52N-2 6 8 3 layers minimum
BACS52N-2A78 6 8 3 layers minimum
BACS52N-3 4 6 3 layers minimum
BACS52N-3A78 4 6 3 layers minimum
BACS52N-48 4 8 3 layers minimum
BACS52N-4 2 4 3 layers minimum
BACS52N-4A78 2 4 3 layers minimum
BACS52N-5 1/0 2 0
ASSEMBLY AND REPAIR OF THE AMP AND BACS52N COPALUM SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-13
Page 32
Oct 15/2015D6-54446
