Table 20 CRIMP TOOLS FOR AMP COPALUM TERMINALS (Continued)
Crimp Barrel Crimp Tool
Aluminum
Wire Size
(AWG)
Copper Wire
Size (AWG)
Basic Unit Head Die Set
Part Number Supplier Part Number Supplier
Part
Number
Suppiler
6 8
1804700-1 AMP 1752787-1 AMP 68007 AMP
122271-1 AMP
69066 AMP 68007 AMP
58422-1 AMP 68007 AMP
69120 AMP
69066 AMP 68007 AMP
58422-1 AMP 68007 AMP
4 6
1804700-1 AMP 1752787-1 AMP
68008 AMP
68008-1 AMP
122271-1 AMP
69066 AMP 68008 AMP
58422-1 AMP 68008 AMP
69120 AMP
69066 AMP 68008 AMP
58422-1 AMP 68008 AMP
2 4
1804700-1 AMP 1752787-1 AMP 68009 AMP
122271-1 AMP
69066 AMP 68009 AMP
58422-1 AMP 68009 AMP
69120 AMP
69066 AMP 68009 AMP
58422-1 AMP 68009 AMP
1/0 2
1804700-1 AMP 1752787-1 AMP 68010 AMP
122271-1 AMP
69066 AMP 68010 AMP
58422-1 AMP 68010 AMP
69120 AMP
69066 AMP 68010 AMP
58422-1 AMP 68010 AMP
2/0 1/0
1804700-1 AMP 1752787-1 AMP 68011-1 AMP
69120 AMP
58422-1 AMP
68011-1 AMP
314964-1 AMP
69066 AMP 314964-1 AMP
3/0 2/0
1804700-1 AMP 1752787-1 AMP 59877-1 AMP
69120 AMP 58422-1 AMP 59877-1 AMP
4/0 3/0 69120 AMP 58422-1 AMP 314948-1 AMP
(1) Make a selection of a terminal from Table 1 through Table 8.
(2) Make a selection of a crimp tool from Table 20. Refer to Paragraph 2.L. and Paragraph 2.M. for
hydraulic crimp tool preparation.
(3) Put the wire in the crimp barrel of the terminal. Refer to Figure 13.
Make sure that:
ASSEMBLY OF AMP (TYCO) COPALUM, MS25435 AND THOMAS & BETTS ALUMINUM
TERMINALS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-14
Page 24
Oct 15/2015D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
