Boeing 707 - Page 655

Table 7 END CAP CRIMP TOOLS (Continued)
End Cap
Crimp Tool
Basic Unit Die
Part Number Color Supplier Part Number Supplier
328856
69272-1 Green Tyco (AMP) - -
WA27XE-EP Green Daniels - -
328857
69272-1 Green Tyco (AMP) - -
WA27XE-EP Green Daniels - -
328858
69272-1 Green Tyco (AMP) - -
WA27XE-EP Green Daniels - -
328859
69272-1 Orange Tyco (AMP) - -
WA27XE-EP Orange Daniels - -
328860
69272-1 Orange Tyco (AMP) - -
WA27XE-EP Orange Daniels - -
328861
69272-1 White Tyco (AMP) - -
WA27XE-EP White Daniels - -
329638 69260-1 Brown Tyco (AMP) - -
(1) Make a selection of an end cap from Table 2.
(2) Make a selection of a crimp tool from Table 7.
(3) Make a selection of a sealant from Table 6.
(4) If it is necessary, cut the wire to make the end perpendicular to the longitudinal axis of the wire.
Make sure that the end of the wire insulation is aligned with the end of the conductor.
(5) Put a small quantity of sealant in the crimp barrel of the end cap. Refer to Figure 1.
ASSEMBLY OF END CAPS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-16
Page 5
Oct 15/2015D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
