Table 2 TERMINAL RECEPTACLE CRIMP TOOLS (Continued)
Wire Size
(AWG)
Receptacle
Crimp Tool
Special Instructions
Basic Unit Head Supplier
26
60790-1 90205-2 - AMP (Tyco) -
60790-2 90205-2 - AMP (Tyco) -
60888-4
90131-2 - AMP (Tyco) -
90131-4 - AMP (Tyco) -
60983-3
90131-2 - AMP (Tyco) -
90131-4 - AMP (Tyco) -
24
60789-2
90204-4 - AMP (Tyco) -
91507-1 - AMP (Tyco) -
1213805-3 2031200-3 AMP (Tyco) -
60940-4
90204-1 - AMP (Tyco) -
90204-4 - AMP (Tyco) -
91507-1 - AMP (Tyco) -
60888-4
90131-2 - AMP (Tyco) -
90131-4 - AMP (Tyco) -
60983-3
90131-2 - AMP (Tyco) -
90131-4 - AMP (Tyco) -
640024-1 90314-1 - AMP (Tyco) 2 wires must be used
22
60789-2
90204-4 - AMP (Tyco) -
91507-1 - AMP (Tyco) -
60940-4
90204-1 - AMP (Tyco) -
90204-4 - AMP (Tyco) -
91507-1 - AMP (Tyco) -
60888-4
90131-2 - AMP (Tyco) -
90131-4 - AMP (Tyco) -
60983-3
90131-2 - AMP (Tyco) -
90131-4 - AMP (Tyco) -
640024-1 90314-1 - AMP (Tyco) 1 or 2 wires can be used
20
60789-2
90204-4 - AMP (Tyco) -
91507-1 - AMP (Tyco) -
60940-4
90204-1 - AMP (Tyco) -
90204-4 - AMP (Tyco) -
91507-1 - AMP (Tyco) -
640024-1 90314-1 - AMP (Tyco) 1 or 2 wires can be used
18 640024-1 90314-1 - AMP (Tyco) -
AMP PRINTED CIRCUIT BOARD TERMINAL RECEPTACLES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-17
Page 3
Oct 15/2015D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
