Table 6 CABLE PREPARATION DIMENSIONS (Continued)
Splice Kit Part Number Dimension
Length
(inch)
Target Tolerance
BACS52R3T3
A 2.10 ±0.02
B 0.38 ±0.02
C 0.28 ±0.02
BACS52R3T4
A 2.10 ±0.02
B 0.38 ±0.02
C 0.28 ±0.02
BACS52R3T5
A 1.00 ±0.02
B 0.38 ±0.02
C 0.28 ±0.02
BACS52R3T6
A 2.10 ±0.02
B 0.38 ±0.02
C 0.28 ±0.02
BACS52R4T1
A 1.00 ±0.02
B 0.38 ±0.02
C 0.28 ±0.02
BACS52R4T2
A 2.10 ±0.02
B 0.38 ±0.02
C 0.28 ±0.02
ASSEMBLY OF BACS52R SHIELDED SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-19
Page 8
