Table 1 gives the CAU of conductors of wire.
Refer to Paragraph 2.C. for the CAU of the shield of different shielded wires and cables.
Table 1
CAU OF CONDUCTORS OF WIRE
Wire Size
(AWG)
Conductor
Type
Maximum O.D.
(inch)
CAU
32
Solid 0.008 0.6
Stranded 0.009 0.6
30
Solid 0.010 1
Stranded 0.012 1
28
Solid 0.013 1.6
Stranded 0.015 1.6
26
Solid 0.016 3
Stranded 0.019 3
24
Solid 0.020 5
Stranded 0.024 5
22
Solid 0.025 8
Stranded 0.030 8
20
Solid 0.032 12
Stranded 0.038 12
18
Solid 0.040 19
Stranded 0.046 19
16
Solid 0.051 24
Stranded 0.059 24
15
Solid 0.057 33
Stranded 0.065 33
2445875 S00061545414_V1
CIRCULAR AREA UNITS OF A CONDUCTOR
