Table 3
SHIELDED SPLICE KIT COMPONENT PART NUMBERS
Splice Kit
Kit Component
Type Part Number Quantity Supplier
BACS52P1N1
Conductor Splice BACS52K1N 1 Tyco
Shield Material D-096-22-07-01 1 Tyco
Sleeve, Outer D-098-93-30-04 1 Tyco
Sleeve, Seal D-098-93-34-01 1 Tyco
Solder Sleeve SO96-3-00 2 Tyco
BACS52P1N2
Conductor Splice BACS52K1N 2 Tyco
Shield Material D-096-22-07-06 1 Tyco
Sleeve, Outer D-098-93-31-02 1 Tyco
Sleeve, Seal D-098-93-34-01 2 Tyco
Solder Sleeve SO96-3-00 2 Tyco
BACS52P2N1
Conductor Splice BACS52K2N 1 Tyco
Shield Material 10494-9 1 Tyco
Sleeve, Outer D-098-93-30-01 1 Tyco
Sleeve, Seal D-098-93-34-01 1 Tyco
Solder Sleeve D-108-11 2 Tyco
BACS52P2N2
Conductor Splice BACS52K2N 2 Tyco
Shield Material 10494-7 1 Tyco
Sleeve, Outer D-098-93-31-02 1 Tyco
Sleeve, Seal D-098-93-34-01 2 Tyco
Solder Sleeve D-108-12 2 Tyco
BACS52P2N3
Conductor Splice BACS52K2N 3 Tyco
Shield Material 10494-7 1 Tyco
Sleeve, Outer D-098-93-31-05 1 Tyco
Sleeve, Seal D-098-93-34-01 3 Tyco
Solder Sleeve D-108-12 2 Tyco
BACS52P3N1
Conductor Splice BACS52K3N 1 Tyco
Seal Insert D-097-10-01-01 2 Tyco
Shield Material 10494-9 1 Tyco
Sleeve, Outer D-098-93-31-01 1 Tyco
Sleeve, Seal D-098-93-33-01 1 Tyco
Solder Sleeve D-108-11 1 Tyco
Solder Sleeve D-108-12 1 Tyco
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 31
Jun 15/2021D6-54446
