Table 3 SHIELDED SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit
Kit Component
Type Part Number Quantity Supplier
BACS52P3N2
Conductor Splice BACS52K3N 2 Tyco
Seal Insert D-097-10-02-01 2 Tyco
Shield Material 10494-7 1 Tyco
Sleeve, Outer D-098-93-32-01 1 Tyco
Sleeve, Seal D-098-93-33-01 2 Tyco
Solder Sleeve D-108-0033 1 Tyco
Solder Sleeve D-108-12 1 Tyco
BACS52P3N3
Conductor Splice BACS52K3N 3 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-32-01 1 Tyco
Sleeve, Seal D-098-93-33-01 3 Tyco
Solder Sleeve SO96-5-00 2 Tyco
BACS52P3N3L
Conductor Splice BACS52K3N 3 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-32-01 1 Tyco
Sleeve, Seal D-098-93-33-01 3 Tyco
Solder Sleeve D-108-0033 1 Tyco
Solder Sleeve SO96-5-00 1 Tyco
D-150-0349
Conductor Splice 323756 1 Tyco
Seal Insert D-097-10-01-01 2 Tyco
Shield Material D-096-22-07-03 1 Tyco
Sleeve, Outer D-440-0124 1 Tyco
Sleeve, Seal D-098-93-31-07 1 Tyco
Solder Sleeve SO96-4-00 2 Tyco
D-150-0350
Conductor Splice 323756 1 Tyco
Seal Insert D-097-10-01-01 2 Tyco
Shield Material D-096-22-07-03 1 Tyco
Sleeve, Outer D-440-0124 1 Tyco
Sleeve, Seal D-098-93-31-07 1 Tyco
Solder Sleeve SO96-3-00 1 Tyco
Solder Sleeve SO96-4-00 1 Tyco
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 32
Jun 15/2021D6-54446
