Table 3 SHIELDED SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit
Kit Component
Type Part Number Quantity Supplier
D-150-0351
Conductor Splice BACS52K3N 3 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-32-01 1 Tyco
Sleeve, Seal D-098-93-33-01 3 Tyco
Solder Sleeve D-108-0033 2 Tyco
D-150-0355
Conductor Splice D-094-05-10-12-02 4 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-32-01 1 Tyco
Sleeve, Seal D-098-93-34-01 4 Tyco
Solder Sleeve D-108-0033 1 Tyco
Solder Sleeve SO96-5-00 1 Tyco
D-150-0356
Conductor Splice D-094-05-10-12-02 3 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-32-01 1 Tyco
Sleeve, Seal D-098-93-34-01 3 Tyco
Solder Sleeve D-108-12 1 Tyco
Solder Sleeve SO96-5-00 1 Tyco
D-150-0360
Conductor Splice BACS52K1N 1 Tyco
Seal Insert D-097-92-19-02 2 Tyco
Shield Material D-096-22-07-01 1 Tyco
Sleeve, Outer D-098-93-34-02 1 Tyco
Sleeve, Seal D-098-93-34-01 1 Tyco
Solder Sleeve SO96-2-00 2 Tyco
D-150-0361
Conductor Splice BACS52K2N 1 Tyco
Seal Insert D-097-92-19-02 2 Tyco
Shield Material D-096-22-07-07 1 Tyco
Sleeve, Outer D-098-93-34-03 1 Tyco
Sleeve, Seal D-098-93-34-01 1 Tyco
Solder Sleeve SO96-2-00 2 Tyco
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 33
Jun 15/2021D6-54446
